Two Cameras, Unlimited Possibilities

Old Legend, New Chapter

The iconic Swedish brand Hasselblad designed and built the L2D-20c aerial camera just for DJI Mavic 3, embedding a professional-grade 4/3 CMOS in an unbelievably compact space. Rigorous Hasselblad standards are applied to both hardware performance and software algorithms, bringing imaging quality to an entirely new level.

Mavic 3 features the Hasselblad Natural Color Solution, the culmination of decades of photographic experience that delivers vivid, natural colors with the simple press of the shutter.

Professional Video Specifications

5.1K Video Recording

DCI 4K/120fps

Apple ProRes 422 HQ

10-bit D-Log

Mavic 3 not only records aerial videos at high resolutions and framerates, but it also captures up to 1 billion colors with a 10-bit D-Log color profile. This delivers more natural gradations of sky coloring with more details retained for greater flexibility in post-production.

Mavic 3 Cine supports Apple ProRes 422 HQ encoding with a maximum data rate of 3772Mbps. It also supports a built-in 1TB SSD and 10Gbps lightspeed data cable to further facilitate professional filming and creation.

Tele Camera

28x Hybrid Zoom 162 mm, f/4.4

Explore Mode

Activate Explore mode to unlock Mavic 3’s second camera – a unique tele camera that lets you effortlessly scout and plan your shots.

When scenes or subjects are far away, use the tele camera to zoom in and save time, or record from a distance without disturbing the subject.

Enhanced Safety

Omnidirectional Obstacle Sensing

Mavic 3 helps you to enjoy collision-free flight so you can focus on getting the best shots possible. Multiple wide-angle vision sensors work seamlessly with a high-performance vision computing engine to sense obstacles in all directions precisely and plan a safe flight route that avoids them.

Advanced RTH

Always end on a high note with Advanced RTH. This updated auto-return function enables Mavic 3 to automatically determine the optimal route back to its home point and execute it quickly.

Whether activated by the user or triggered by signal loss, Mavic 3 can easily return to the home point safely in adequate lighting conditions.

Don’t Just Fly. Enjoy.

APAS 5.0

Mavic 3 makes flight more fun than ever with a recording that is no longer interrupted by obstacles along the way. When flying, Mavic 3 continually senses objects in all directions and bypasses them quickly and smoothly.

• Enjoy every flight, even in complex environments.
• Record smooth footage, even when encountering obstacles.

O3+ Transmission and Beyond

• 46 Minutes Extended Flight Time
• 15 km Video Transmission Range
• 1080p/60fps FHD High-Framerate Live Feed
• Extreme-Precision Positioning Technology

Additional Features

• Wi-Fi 6 QuickTransfer [10]
• ActiveTrack 5.0 [1][10]
• master shots [10]

Specifications:

Aircraft

• Takeoff Weight: Mavic 3: 895 g
  Mavic 3 Cine: 899 g
• Dimensions (Folded/Unfolded): Folded (without propellers) 221×96.3×90.3 mm
  (Length×Width×Height)
  Unfolded (without propellers) 347.5×283×107.7 mm
  (Length×Width×Height)
• Diagonal Length: 1 mm
• Max Ascent Speed: 1 m/s (C mode)
  6 m/s (N mode)
  8 m/s (S mode)
• Max Descent Speed: 1 m/s (C mode)
  6 m/s (N mode)
  6 m/s (S mode)
• Max Flight Speed (at sea level, no wind): 5 m/s (C mode)
  15 m/s (N mode)
  19 m/s (S mode)
• Max Service Ceiling Above Sea Level: 6000 m
• Max Flight Time (no wind): 46 minutes
• Max Hovering Time (no wind): 40 minutes
• Max Flight Distance: 30 km
• Max Wind Speed Resistance: 12 m/s
• Max Tilt Angle: 25° (C mode)
  30° (N mode)
  35° (S mode)
• Max Angular Velocity: 200°/s
• Operating Temperature: -10° to 40° C (14° to 104° F)
• GNSS: GPS + Galileo + BeiDou
• Hovering Accuracy Range: Vertical: ±0.1 m (with Vision Positioning); ±0.5 m
  (with GNSS Positioning)
  Horizontal: ±0.3 m (with Vision Positioning); ±0.5 m
  (with High-Precision Positioning System)
• Internal Storage: Mavic 3: 8 GB (available space is approx. 7.2 GB)
  Mavic 3 Cine: 1TB (available space is approx. 934.8 GB)

Hasselblad Camera

• Sensor: 4/3 CMOS, Effective pixels: 20 MP
• Lens: FOV: 84°
  Format Equivalent: 24 mm
  Aperture: f/2.8 to f/11
  Focus: 1 m to ∞ (with autofocus)
• ISO Range: Video: 100-6400
  Still Image: 100-6400
• Shutter Speed: Electronic Shutter: 8-1/8000 s
• Max Image Size: Main Unit: 5280×3956
• Still Photography Modes: Single shot: 20MP Photos
  Automatic Exposure Bracketing (AEB): 20 MP, 3/5 bracketed frames at 0.7 EV
  Timed: 20 MP, 2/3/5/7/10/15/20/30/60 s
• Video Resolution: Apple ProRes 422 HQ
  1K: 5120×2700@24/25/30/48/50fps
  DCI 4K: 4096×2160@24/25/30/48/50/60/120*fps
  4K: 3840×2160@24/25/30/48/50/60/120*fpsH.264/H.265
  5.1K: 5120×2700@24/25/30/48/50fps
  DCI 4K: 4096×2160@24/25/30/48/50/60/120*fps
  4K: 3840×2160@24/25/30/48/50/60/120*fps
  FHD: 1920×1080p@24/25/30/48/50/60/120*/200*fps* Framerates above are recording framerates. Videos will be played as slow-motion videos.
• Max Video Bitrate: 264/H.265 Bitrate: 200 Mbps
• Supported File Formats: exFAT
• Photo Format: JPEG/DNG (RAW)
• Video Formats: Mavic 3:
  MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)Mavic 3 Cine:
  MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
  MOV (Apple ProRes 422 HQ)

Tele Camera

• Sensor: 1/2-inch CMOS
• Shutter Speed: Electronic Shutter: 2-1/8000 s
• Lens: FOV: 15°
  Format Equivalent: 162mm
  Aperture: f/4.4
  Focus: 3 m to ∞
• ISO Range: Video: 100-6400
  Still Image: 100-6400
• Max Image Size: 4000×3000
• Photo Format: JPEG
• Video Formats: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265)
• Still Photography Modes: Single shot: 12MP Photos
• Video Resolution: H264/H.265
  4K: 3840×2160@30 fps
  FHD: 1920×1080@30 fps
• Digital Zoom: 4x

Gimbal

• Stabilization: 3-axis motorized (tilt, roll, pan)
• Mechanical Range: Tilt: -135° to 100°
  Roll: -45° to 45°
  Pan: -27° to 27°
• Controllable Range: Tilt: -90° to 35°
  Pan: -5° to 5°
• Max Control Speed (tilt): 100°/s
• Angular Vibration Range: ±0.007°

Sensing

• Sensing System: Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft
• Forward: Measurement Range: 0.5-20 m
  Detection Range: 0.5-200 m
  Effective Sensing Speed: Flight Speed ≤ 15m/s
  FOV: Horizontal 90°, Vertical 103°
• Backward: Measurement Range: 0.5-16 m
  Effective Sensing Speed: Flight Speed ≤ 12m/s
  FOV: Horizontal 90°, Vertical 103°
• Lateral: Measurement Range: 0.5-25 m
  Effective Sensing Speed: Flight Speed ≤ 15m/s
  FOV: Horizontal 90°, Vertical 85°
• Upward: Measurement Range: 0.2-10 m
  Effective Sensing Speed: Flight Speed ≤ 6m/s
  FOV: Front and Back 100°, Left and Right 90°
• Downward: Measurement Range: 0.3-18 m
  Effective Sensing Speed: Flight Speed ≤ 6m/s
  FOV: Front and Back 130°, Left and Right 160°
• Operating Environment: Forward, Backward, Left, Right, and Upward: Surface with a clear pattern and adequate lighting (lux>15)
  Downward: Surface with a clear pattern and adequate lighting (lux >15). Diffuse reflective surface with diffuse reflectivity>20% (e.g. wall, tree, person)

Video Transmission

• Video Transmission System: O3+
• Live View Quality: Remote Controller: 1080p@30fps/1080p@60fps
• Operation Frequency: 2.400-2.4835 GHz
  725-5.850 GHz
• Max Transmission Distance (unobstructed, free of interference, and aligned with controller): 2.400-2.4835 GHz; 5.725-5.850 GHz
  FCC: 15 km
  CE: 8 km
  SRRC: 8 km
  MIC: 8 km
• Signal Transmission Ranges (FCC): Strong Interference (urban landscape, limited line of sight, many competing signals): Approx. 1.5-3 km
  Medium Interference (suburban landscape, open line of sight, some competing signals): Approx. 3-9 km
  Low Interference (open landscape abundant line of sight, few competing signals): Approx. 9-15 km data is tested under different standards in open areas free of interference. It only refers to the maximum, one-way flight distance without considering Return Home. Please pay attention to RTH prompts in the DJI Fly app during the actual flight.
• Max Download Bitrate: O3+:
  5MB/s (with RC-N1 remote controller)
  15MB/s (with DJI RC Pro remote controller)
  Wi-Fi 6:
  80MB/s
• Latency (depending on environmental conditions and mobile device): 130 ms (with RC-N1 remote controller)
  120 ms (with DJI RC Pro remote controller)
• Antennas: 4 antennas, 2T4R
• Transmitter Power (EIRP): 2.4 GHz: ≤33 dBm (FCC); ≤20 dBm (CE/SRRC/MIC)
  8 GHz: ≤33 dBm (FCC), ≤30 dBm(SRRC), ≤14 dBm(CE)

Battery

• Capacity: 5000 mAh
• Voltage: 15.4 V
• Charging Voltage Limit: 17.6 V
• Battery Type: LiPo 4S
• Energy: 77 Wh
• Weight: 335.5 g
• Charging Temperature: 5° to 40° C (41° to 104° F)

Battery Charger

• Input: 100-240 V AC, 47-63 Hz, 2.0 A
• USB-C Output: USB-C: 5.0 V⎓0 A/9.0 V⎓5.0 A/12.0 V⎓5.0 A/15.0 V⎓4.3 A/20.0 V⎓3.25 A/5.0~20.0 V⎓3.25 A
• USB-A output: USB-A: 5 V⎓2 A
• Rated Power: 65 W

Charging Hub

• Input: USB-C: 5-20 V⎓0 A max
• Output: Battery: 12-17.6 V⎓0 A max
• Rated Power: 65 W
• Charging Type: Charges three batteries in sequence.
• Charging Temperature Range: 5° to 40° C (41° to 104° F)

Car Charger

• Input: Car Power Input: 12.7-16 V⎓5 A, rated voltage 14 V DC
• Output: USB-C: 5.0 V⎓0 A/9.0 V⎓5.0 A/12.0 V⎓5.0 A/15.0 V⎓4.3A/20.0 V⎓3.25 A/5.0~20.0 V⎓3.25 A
  USB-A: 5 V⎓2 A
• Rated Power: 65 W
• Charging Time: 96 minutes
• Charging Temperature Range: 5° to 40° C (41° to 104° F)

Storage

• Recommended microSD Cards: Standard bitrate video recommended microSD Cards:
  H.265 :
  5.1K: 5120×2700@24/25/30/48/50fps
  DCI 4K : 4096×2160@24/25/30/48/50/60/120fps
  4K: 3840×2160@24/25/30/48/50/60/120fps
  FHD : 1920×1080@24/25/30/48/50/60/120/200fps
  H.264 :
  DCI 4K : 4096×2160@24/25/30/48/50/60fps
  4K: 3840×2160@24/25/30/48/50/60fps
  FHD: 1920×1080@24/25/30/48/50/60/120/200fps
  SanDisk Extreme Pro 64G v30 A2 microSDXC
  SanDisk Extreme Pro 128G v30 A2 microSDXC
  SanDisk Extreme Pro 256G v30 A2 microSDXC
  SanDisk Extreme Pro 400G v30 A2 microSDXC
  SanDisk High Endurance 64G v30 XC I microSDXC
  SanDisk High Endurance 128G v30 XC I microSDXC
  SanDisk High Endurance 256G v30 XC I microSDXC
  SanDisk Extreme 128G v30 A2 microSDXC
  SanDisk Extreme 256G v30 A2 microSDXC
  SanDisk Extreme 512G v30 A2 microSDXC
  Lexar 667x 64G microSDXC
  Lexar 667x 128G microSDXC
  Lexar 667x 256G microSDXC
  Lexar High Endurance 64G V30 XC I microSDXC
  Lexar High Endurance 128G microSDXC
  Samsung Evo Plus 64G microSDXC
  Samsung Evo Plus 128G microSDXC
  Samsung Evo Plus 256G microSDXC
  Samsung Evo Plus 512G microSDXC” High bitrate video recommended microSD Cards:
  H.264 :
  5.1K: 5120×2700@24/25/30/48/50fps
  DCI 4K: 4096×2160@120fps
  4K: 3840×2160@120fps
  SanDisk Extreme Pro 64G v30 A2 microSDXC
  SanDisk Extreme Pro 128G v30 A2 microSDXC
  SanDisk Extreme Pro 256G v30 A2 microSDXC
  SanDisk Extreme Pro 400G v30 A2 microSDXC
  SanDisk High Endurance 64G v30 XC I microSDXC
  SanDisk High Endurance 128G v30 XC I microSDXC
  SanDisk High Endurance 256G v30 XC I microSDXC
  Lexar High Endurance 64G V30 XC I microSDXC
  Lexar High Endurance 128G microSDXC
  Lexar 667x 64G microSDXC Lexar 667x 128G microSDXC
  Lexar 667x 256G microSDXCMicroSD Cards are not capable of recording Apple ProRes 422 HQ codec.

• SSD Specs: Capacity: 1 TB
  Max Read Speed: 700MB/s*
  Max Write Speed: 471MB/s** Data refers to the read and write speed inside the aircraft. The actual read and write speed of computers and other external devices may affect the actual speed.

DJI RC-N1 Remote Controller

• Remote Controller Transmission System: When used with different aircraft hardware configurations, DJI RC-N1 Remote Controllers will automatically select the corresponding firmware version for updating and support the following transmission technologies enabled by the hardware performance of the linked aircraft models:
  DJI Mini 2/ DJI Mavic Air 2: O2
  b. DJI Air 2S: O3
  c. DJI Mavic 3: O3+
• Max Supported Mobile Device Size: 180×86×10 mm (Length×Width×Height)
• Operating Temperature: 0° to 40° C (32° to 104° F)
• Transmitter Power (EIRP): 4 GHz:
  ≤26 dBm (FCC), ≤20 dBm (CE/SRRC/MIC)
  5.8 GHz:
  ≤26 dBm (FCC/SRRC), ≤14 dBm (CE)
• Battery Life: Without charging any mobile device: 6 hr;
  when charging mobile device: 4 hr
• Supported USB Port Types: Lightning, Micro USB, USB-C

Compare Models:

Notes:

1. ActiveTrack is not available at video resolutions higher than 4K or frame rates over 60fps.
2. DJI Mavic 3 Cine supports Apple ProRes 422 HQ and H.264/H.265 encoding, while Mavic 3 only supports H.264/H.265 encoding.
3. Actual available storage space may be reduced due to system configuration. For more details, see the Mavic 3 specs.
4. DO NOT use the aircraft in severe weather conditions including heavy wind exceeding 13.8 m/s, snow, rain, fog, hail, or lightning. DO NOT fly the aircraft 6,000 m (19,685 ft.) or higher above sea level. DO NOT fly the aircraft in environments where the temperature is below -10° C (14° F) or above 40° C (104° F). DO NOT take off from moving objects such as cars or boats. DO NOT fly close to reflective surfaces such as water or snow. Otherwise, the vision system may be limited. When the GNSS signal is weak, fly the aircraft in environments with good lighting and visibility. Low ambient light may cause the vision system to function abnormally. DO NOT fly near areas with magnetic or radio interference. A common source of magnetic or radio interference includes Wi-Fi hotspots, routers, Bluetooth devices, high-voltage lines, large-scale power transmission stations, radar stations, mobile base stations, and broadcasting towers. Be careful when taking off in desert or beach areas to avoid sand entering the aircraft. Fly the aircraft in open areas. Buildings, mountains, and trees may block the GNSS signal and affect the onboard compass.
5. Measured with Mavic 3 flying at a constant speed of 32.4 kph in a windless environment at sea level until the battery reached 0%. Data is for reference only. Please pay attention to the RTH reminder on the DJI Fly app during the flight.
6. Unobstructed, free of interference, and when FCC-compliant. The maximum flight range specification is a proxy for radio link strength and resilience. Always follow local rules and regulations and fly your drone within your visual line of sight unless otherwise permitted.
7. Unobstructed and free of interference. Actual resolution may vary depending on the quality of the transmission signal.
8. Sold separately. This function will be available in January 2022 through firmware updates.
9. Unobstructed, free of interference, and when FCC-compliant. The maximum flight range specification is a proxy for radio link strength and resilience.
10. This function will be available in January 2022 through firmware updates.
