Recording Channel | 2 |
Recording Format | WAV / (44.1kHz/16bit,44.1kHz/24bit,48kHz/16bit,48kHz/24bit,96kHz/16bit, 96kHz/24bit) |
Playback Format | WAV / (44.1kHz/16bit,44.1kHz/24bit,48kHz/16bit,48kHz/24bit,96kHz/16bit, 96kHz/24bit) |
A/D Conversion | 24-bit,128x oversampling |
D/A Conversion | 24-bit,128x oversampling |
Signal Processing | 32-bit |
LCD | LCD 128*64(with light) |
Inputs | - Built-in 90° XY stereo mic Maximum input sound pressure: 110dB SPLSensitive:-35dB Unidirectional cardioid |
Outputs | 3.5mm stereo headphone jack: MC IN to Headphone/LNE OUT: Maximum Gain 48dBLINE IN to Headphone/ LlNE OUT: Maximum Gain 36dB |
Built-in Speaker | 0.5w/8Ω |
USB Jack | Type-C |
Power Required | 2AA batteries (Ni-MH or Alkaline)USB-C DC 5V/1A |
Recording Hours | 4 hours under 96kHz/24bit (wav)(8GB SD card) / 13.5 hours under 44.1kHz/16bit (wav)(8GB SD card) |
Weight | 155g (5.47oz) |
Dimension | 157mm*45mm*25.8mm |
SD Card Capacity | Support up to 128GB |
Packing List | BY-R1 handy recorder Foam windscreen microSD card (8GB) Carrying pouch USB-C cable |
Warranty | 2-Year Brand Warranty |
- Records up to 96kHz/24bit audio files
- Up to 2-channel simultaneous recording
- Key locking function to prevent inadvertent operation
- Adjusting monitoring volume and input gain level
- High-resolution LCD - see vital information at a glance.
